Highlights
Large Color Display
The large color display presents critical information clearly, which is readable even in direct sunlight.
Remote Control Head
The remote control kit offers you great flexibility . You can install the control console and the main units at separate locations based on actual requirements.
Dual-slot Pseudo Trunk
The free slot can be allocated to enhance frequency efficiency and timely response under emergency.
Dual Modes
The MD78Xi can operate in analog or digital mode, ensuring a smooth analog-to-digital migration.
Long-range Communication
With 50 W output power and higher RX sensitivity, the MD78Xi dramatically extends the communication coverage.
Full Duplex Call (Optional)
The MD78Xi can make a full duplex call to the PD98X, other MD78Xi, telephone, or smartphone in DMO, TMO, or repeater mode.
Specifications
| General | |
| Frequency Range | VHF: 136-174MHz; UHF1: 400-470MHz; UHF3: 350-400MHz |
| Channel Capacity | 1024 |
| Zone Capacity | 64 |
| Channel Spacing | 12.5kHz/20kHz/25kHz |
| Operating Voltage | 13.6V±15% |
| Current Drain(Receive) | 1W＜2A; 45W＜12A; 50W＜12A; 25W＜8A |
| Current Drain(Transmit) | ＜2.0A |
| Dimensions(H×W×D) mm | 174 x 60 x 200 mm |
| Weight | 1.7kg |
| Display | LCD Display:2.0 inch, 4 rows |
| Receiver | |
| Sensitivity(Analog) | 0.22μV (12dB SINAD) 0.18μV (12dB SINAD) (Typical) 0.35μV( 20dB SINAD) |
| Sensitivity(Digital) | 0.22μV/BER5% |
| Rated Audio Power Output(Internal) | 3W @20ohm load |
| Rated Audio Power Output(External) | 7.5W @8ohm load |
| Max. Audio Power Output(Internal) | 8W @20ohm load |
| Max. Audio Power Output(External) | 20W @8ohm load |
| Transmitter | |
| RF Power Output | Low power:1-25W High power :UHF: 1-45W High power :VHF: 5-50W |
| Digital Vocoder Type | AMBE+2™ or SELP |
| Environmental | |
| Operating Temperature | -30℃～+60℃ |
| Storage Temperature | -40℃～+85℃ |
| ESD | IEC 61000-4-2(level 4) ±8kV(Contact) ±15kV(Air) |
| Dust & Water Protection | IP54 |
| Humidity | MIL-STD-810 C/D/E/F/G |
| Vibration,Drop&Shock | MIL-STD-810 C/D/E/F/G |
| GPS Specifications | |
| Horizontal Position Accuracy | <5m |
| General | |
|---|---|
| Frequency Range | VHF: 136-174MHz; UHF1: 400-470MHz; UHF3: 350-400MHz |
| Channel Capacity | 1024 |
| Zone Capacity | 64 |
| Channel Spacing | 12.5kHz/20kHz/25kHz |
| Operating Voltage | 13.6V±15% |
| Current Drain(Receive) | 1W＜2A; 45W＜12A; 50W＜12A; 25W＜8A |
| Current Drain(Transmit) | ＜2.0A |
| Dimensions(H×W×D) mm | 174 x 60 x 200 mm |
| Weight | 1.7kg |
| Display | LCD Display:2.0 inch, 4 rows |
| Receiver | |
|---|---|
| Sensitivity(Analog) | 0.22μV (12dB SINAD) 0.18μV (12dB SINAD) (Typical) 0.35μV( 20dB SINAD) |
| Sensitivity(Digital) | 0.22μV/BER5% |
| Rated Audio Power Output(Internal) | 3W @20ohm load |
| Rated Audio Power Output(External) | 7.5W @8ohm load |
| Max. Audio Power Output(Internal) | 8W @20ohm load |
| Max. Audio Power Output(External) | 20W @8ohm load |
| Transmitter | |
|---|---|
| RF Power Output | Low power:1-25W High power :UHF: 1-45W High power :VHF: 5-50W |
| Digital Vocoder Type | AMBE+2™ or SELP |
| Environmental | |
|---|---|
| Operating Temperature | -30℃～+60℃ |
| Storage Temperature | -40℃～+85℃ |
| ESD | IEC 61000-4-2(level 4) ±8kV(Contact) ±15kV(Air) |
| Dust & Water Protection | IP54 |
| Humidity | MIL-STD-810 C/D/E/F/G |
| Vibration,Drop&Shock | MIL-STD-810 C/D/E/F/G |
| GPS Specifications | |
|---|---|
| Horizontal Position Accuracy | <5m |
