Highlights

hytera image
Dual Modes
PD78X/78XG can operate in either analog or digital mode . It is compatible with the prevalent analog system , ensuring a smooth analog-to-digital transition.
hytera image
Superior Audio Quality
With narrowband codec and digital error-correction technologies,PD78X / 78XG delivers superior voice under noisy environments.
hytera image
Reliable and Durable
MIL-STD-810 C/D/E/F/G and IP67 certified, the PD78X/78XG is built to perform in the toughest conditions.
hytera image
Audio and Data Encryption
Support basic encryption , enhanced encryption,and the Scrambler feature (optional).
hytera image
Auto Mode Switch
Support automatic switch between DMR trunking and analog trunking, and between DMR trunking and conventional mode according to the network coverage.
hytera image
Antenna

Dual-timeslot communication in DMO mode doubles efficiency

Man down alarm

Support man down alarm(optional upon delivery)

Speaker

The AGC technology maintains a suitable voice volumeand the built-in 1W speaker further ensures clear and crisp voice.

Position

GPS (optional upon delivery)

Battery

Longer battery life

Display

Large LCD Color Display and Full Keypad

Specifications

General
Frequency Range UHF1:400-470MHz; UHF2:450-520MHz; UHF3:350-400MHz; UHF5:806-825MHz(only transmit) 851-870MHz(transmit+receive)896-902MHz(only transmit) 935-941MHz(transmit+receive); VHF1:136-174MHz; VHF3:210-270MHz
Channel Capacity 1024
Zone Capacity 64
Channel Spacing 25/20/12.5KHz
Operating Voltage 7.4V(rated)
Duty Cycle
Battery 2000mAh(Li-Ion)(standard); 2500mAh(Li-Ion)(optional)
Battey Life(5/5/90 Duty Cycle,High TX Power) Analog / digital : 15.5hrs/20hrs
Dimensions(H×W×D) mm 125 × 55 × 37
Weight 355g
Display LCD screen:160×128 pixels,65536 colors,1.8inch,6 lines
Receiver
Rated Audio Power Output 0.5W
Rated Audio Power Output(External)
Transmitter
RF Power Output UHF1/UHF2/UHF3:4W/1W; VHF:5/1W; UHF5:3W/1W(806-870MHz), 2.5W/1W(896-941MHz)
Environmental
Operating Temperature -30℃~+60℃
Storage Temperature -40℃~+85℃
Dust & Water Protection IP67
General
Frequency Range UHF1:400-470MHz; UHF2:450-520MHz; UHF3:350-400MHz; UHF5:806-825MHz(only transmit) 851-870MHz(transmit+receive)896-902MHz(only transmit) 935-941MHz(transmit+receive); VHF1:136-174MHz; VHF3:210-270MHz
Channel Capacity 1024
Zone Capacity 64
Channel Spacing 25/20/12.5KHz
Operating Voltage 7.4V(rated)
Duty Cycle
Battery 2000mAh(Li-Ion)(standard); 2500mAh(Li-Ion)(optional)
Battey Life(5/5/90 Duty Cycle,High TX Power) Analog / digital : 15.5hrs/20hrs
Dimensions(H×W×D) mm 125 × 55 × 37
Weight 355g
Display LCD screen:160×128 pixels,65536 colors,1.8inch,6 lines
Receiver
Rated Audio Power Output 0.5W
Rated Audio Power Output(External)
Transmitter
RF Power Output UHF1/UHF2/UHF3:4W/1W; VHF:5/1W; UHF5:3W/1W(806-870MHz), 2.5W/1W(896-941MHz)
Environmental
Operating Temperature -30℃~+60℃
Storage Temperature -40℃~+85℃
Dust & Water Protection IP67
