Specifications of ECN50-P
- Specifications
| Specifications | |
|---|---|
| Weight | about 474g |
| Colour | black |
| PTT key | available |
| PTT cycles | ≥ 100,000 |
| VOX | YES (activation in conjunction with the radio's VOX function) |
| Emergency Key | none |
| Radio connector | 13-pin flat connector |
| Microphone sensitivity | -52 ±3 dB @1kHz 3.0V 2.2K, 0dB=1V/Pa |
| Speaker power | 200 mW (rated) 500 mW (max.) |
| Speaker impedance | 2 x 32 Ω ±15% @1kHz |
| Speaker sensitivity | 76±4 dB/0.2 W @ 50 cm, 1 kHz |
| Hearing Protection Noise Reduction Rating (NRR) | up to 27 dB |
| Ingress protection | IP54 |
| Operating temperature | –30℃ to 60℃ |
| Storage temperature | –40℃ to 60℃ |
| Suitable radios | HP505, HP565, HP605, HP685, HP705, HP785, PDC550, PDC680 A10, PDM680, PTC680 A10, PD605, PD665, PD685, X1e, X1p, Z1p, PT590 |
