Z1p Ultra-thin TETRA Portable Radio


Handheld | TETRA

Z1P Ultra-thin TETRA Portable Radio has all the mission-critical communication features exquisitely engineered into a compact, slim, and ruggedized frame. Its ergonomic design, features such as hands-free calls in duplex mode, and choices of wireless accessories make law-enforcing activities highly efficient and discreet. Multiple security mechanisms, depending on the users’ requirements, are adopted to encrypt voice and data transmission and secure communications.

Highlights of Z1p


Weighing just 255g, easy to carry. Only 23 mm in thickness, easy to hold. Tactile keys, easy to operate.


Provide a duplex hands-free function, through echo cancellation technology, so that customers can obtain higher-quality call results. 3W of output and DMO relay function can effectively expand signal coverage.


Noise reduction technology can provide clear and enhanced audio output in noisy environment. Provide authentication, air interface encryption, end-to-end and other encryption methods to provide high-level security for industrial users.

Specifications of Z1p

Frequency Range 380-430 MHz
Dimensions(H×W×D) mm 120 mm × 58 mm × 23 mm (with 1400 mAh standard battery); 120 mm × 58 mm × 26 mm (with 1800 mAh option battery)
Weight 268 g(with 1400 mAh standard battery and antenna); 292 g(with 1800 mAh option battery and antenna);
Operating Voltage 7.4 V
Battery 1400 mAh Li-lon battery (standard); 1800 mAh Li-lon battery (option)
Battery Life (TMO 5/5/90 duty cycle) >16 hours (1400 mAh); >20 hours (1800 mAh)
User Interface
Display 1.8 inch,160*128 pixels,262144 colors
Talk Group-TMO 6000
Talk Group-DMO 4000
Telephone book 2000
